From model to metal: How connected data helps steel contractors build better

From model to metal: How connected data helps steel contractors build better

The relationship between steel detailers and fabricators is one of the most important links in the entire construction process. Detailers create the precise drawings and models that guide fabrication, and fabricators turn that information into the beams, columns and assemblies that hold the structure together. On paper, it sounds straightforward, but in reality, information sharing between these groups can be one of the toughest parts of any project.

At the heart of the issue is disconnected data. When a detailer sends information that doesn't match the fabricator’s database, such as wrong shapes, incorrect grades or unavailable finishes, the fabricator must spend time reconciling those differences. If submittals stall in an inbox or file errors go unnoticed, projects face costly delays. When communication is siloed, both parties are left guessing whether the information they sent or received is accurate, complete and usable.

In short, when fabricators and detailers aren't aligned, projects slow down, costs go up and trust between teams can suffer.

A better way to work together

Advances in connected construction technology are helping to bridge this gap. Common data environments, such as Trimble Connect, allow all project stakeholders to seamlessly share data with full transparency into what files were sent, by whom and in what format. This means that detailers can validate their models against the exact materials and profiles in the fabricator’s database before submittals are sent, and fabricators receive data they can trust without spending hours reworking mismatched files. Both sides eliminate guesswork by gaining visibility into the process.

One of the most powerful examples of this new approach is the Tekla Connector, which links Tekla Structures for detailing with Tekla PowerFab for fabrication. This workflow is designed to reduce requests for information, minimize phone calls and accelerate approvals, helping detailers and fabricators work as one team.

This connected workflow offers:

• Shared settings: Fabricators using Tekla PowerFab share an up-to-date catalog of profiles, materials, finishes and real-time status with the detailer. Rather than override the detailer settings, the Tekla Connector compares them and flags mismatches.

• Model validation: Detailers can validate their model against the fabricator’s settings, ensuring that the size, shapes, grades and finishes used in the model actually exist in the fabricator’s database before submission. This process reduces the number of changes required later.

• Flexible submittals: Detailers can create and send submittals for estimating, procurement, drawings and fabrication directly from Tekla Structures to Tekla PowerFab at any stage of the project. They can also export packages locally to check data before sending.

• Transparency and tracking: Detailers can see whether a submittal has been received, when it was downloaded and by whom. No more wondering if an email got lost or if a file made it through.

• Real-time status sharing: Fabricator statuses are shared directly in the model environment, giving detailers instant feedback on actions without needing to wait for an email or phone call.

When detailers and fabricators can seamlessly share information, projects move faster with fewer mistakes and less waste. The Tekla Connector demonstrates how connected technology can take the pain out of collaboration, transforming it from a source of frustration into a competitive advantage.

At the end of the day, detailers and fabricators want the same thing: accurate, constructible steel delivered on time. By eliminating data silos and embracing connected workflows, both sides can focus on what they do best while working together as true partners in project success

For more information on the Tekla Connector, watch our on-demand webinar now.
