Trimble SysQue

Trimble SysQue empowers detailers, engineers and fabricators to work in tandem to build constructible, real-world, digitized MEP models in Autodesk Revit.

Request a demo

Stay current with managed content
Enhance your model
Collaborate with stakeholders
Improve your workflows

Work from a continually evolving database of over eight million parts, and request additional content.

Transforming MEP constructible models

Detail on top of a generic Revit model

Leverage SysQue real-world content across electrical, piping, mechanical, and sheet metal systems to upgrade your generic Revit drawings into constructible SysQue models.

Create construction-ready models

Achieve LOD 400 models ready for constructibility.

Fabricate from your model

Quickly output electrical systems, piping, plumbing or ductwork into spool sheets for pre-fabrication.

Manage your submittals

Export PDFs with SysQue content contained in your model.

Lay out detailed hangers and supports

Layout Hangers in your model quickly then export out to Trimble's Field Link application.

Model electrical systems quickly

Quickly detail real-world conduit and cable tray inside of your model with your systems and specifications.

Produce pipe CAM files directly from your model

Export the necessary SysQue model elements in a file format that can be imported directly into PypeServer ensuring data is accurate and complete.

Define your ductwork specifications

Convert generic Revit families to SMACNA and DW144 specifications out of the box.

Connect your model to your estimate

Connect your model to the estimate for better project insight, visibility and more accurate project execution with model-based estimating, a VDC Pro+ exclusive feature.

Export to fabrication software

Save hours of manual input by downloading your detailed model data directly from SysQue and importing it into CAM software.

TESTIMONIALS

Over the last few years we’ve seen a push back on designers to take on a bigger responsibility of the coordination efforts before they even go out to bid. They want a higher level of detail in their designs early in the process and we have tried to stay ahead of that curve. We are now able to competitively bid in a much bigger sector of the construction market due to Trimble SysQue.

— Dan Cedeno

Project Manager and BIM/ Database Manager at J.M. Brennan
